Note: Clean and lubricate axle and chassis control
arm mounting brackets with a good quality chassis
grease to ease installation.

7. Tighten front and rear control arm mounting bolts to

80 ft./lb. torque.

Note: The adjustable feature of this arm enables you
to correctly locate the rear end in relation to the
chassis and to compensate for altered ride heights.

8. Follow the same above procedure for installation

of Adjustable Control Arm on other side of vehicle.

9. Lubricate control arm bushings with a good quality

chassis grease.

10. Once arms are installed you can begin to adjust.

11. The pinion angle must now be checked and adjusted if

necessary. The angle between the drive shaft and the
rear end yoke must be between 4 and 6 degrees down.

12. With pinion angle set, tighten all fasteners securely.

13. Install wheels and properly tighten lug nuts to

wheel manufacturers specifications.

14. Carefully remove support stands and lower vehicle

to ground.

THIS COMPLETES THE INSTALLATION.

YOU CAN NOW ROCK-N-ROLL!

IMPORTANT!

Periodically check to make sure that all mounting

hardware is securely tightened. Use a good

quality chassis grease to keep bushings and

sleeves properly lubricated.

TECHNICAL SERVICE

A highly trained technical service department is

maintained by Lakewood Industries to answer your

technical questions, provide additional product

information and offer various recommendations. See

your local retailer of Lakewood products for specific

prices. For best results, technical service calls,

correspondence and warranty questions should be

directed to the following address:

Lakewood Industries

10601 Memphis Ave. #12

Cleveland, Ohio 44144

Phone 216-688-8300

8:30 A.M.-5:00 P.M. EST

www.lakewood-industries.com

Recommended Optional Lakewood Products for Ford:

• For drag racing, use Lakewood Traction… Action Lift

Bars for 1979-98 Mustangs #21900, for 1999-03
Mustangs #21901

• For drag racing, the factory rear shocks should be

replaced with a 50/50 ratio shock absorber (1979-1993
Mustangs) #40301

• Front Drag Struts are also available for

1979-93 model years in ratios of 70/30 #40501, or
90/10 #40511. Also 1994-2003 Mustangs 70/30 #40506,
and 90/10 #40516

• Rear Lower Control Arms with polyurethane bushings

to reduce flex and provide stability for 1779-98
Mustangs #20150, and 1999-03 Mustangs #20151

• Ford Lower Control Arms

1979-1993 Ford Mustang, Capri,

#21314

1980-1985 Ford Thunderbird, Cougar

#21314

1978-1982 Ford Fairmont

#21314

1981-1982 Ford Granada, Monarch, Zephyr

#21314

• Replacement Bushing Set. Bushings for all Lakewood

Control Arms and Traction Bars #20538

• Bolt-in Drive Shaft Safety Loop for 1979-03 Mustangs

#18017

Recommended Optional Lakewood Products for GM:

• For drag racing, the factory rear shocks should be

replaced with a 50/50 ratio shock absorber available
for 1982-92 model years (#40301).

• Replacement Bushing Set for Traction Bars (#20538).

• Front Drag Struts are also available for

1982-92 model years in ratios of 70/30 (#40500) or
90/10 (#40510).

• Bolt-in Safety Drive Shaft Loop available for 1982-92

model years (#18020), 1993-2002 model years
(#18022).

• GM Lower Control Arms

1964-1972 GM A-Body Cars: Chevelle, GTO,

Cutlass, Skylark, G.S., 442

#21312

1978-1987 GM G-Body Cars: Regal, G.N.,

Monte Carlo, Cutlass, Grand Prix

#21313

• GM No-Hop Traction Bars

1964-72 Skylark, Chevelle, Cutlass, 442, Grand Prix,

GTO, Lemans, Malibu, Monte Carlo

#21609

1978-87 Chevelle, Cutlass, 442, Grand Prix, Malibu,

Monte Carlo, Regal

#21610

See your local retailer of Lakewood products

for specific prices.

RETAIN THIS INSTRUCTION SHEET FOR FUTURE REFERENCE.
