Mallory Ignition ACCEL POINTS ELIMINATOR IGNITION MODULE PN 2005 User Manual
Page 2
COIL
(+)
(—)
12
3
+12V FROM IGNITION SWITCH
GROUND TO ENGINE BLOCK
RED
GREEN
BROWN
COIL
(+)
(—)
12
3
+12V FROM IGNITION SWITCH
GROUND TO ENGINE BLOCK
LOOM RESISTANCE WIRE
RED
GREEN
BROWN
NOTE—
When using an ACCEL 275+
or 300+ or other aftermarket
ignition control, connect the
MODULE according to the
instructions supplied with the
ignition control.
WITH RESISTANCE WIRE
WITH ACCEL 8140, 8140C, 140108, 140205, 140305 OR 140009 COILS
COIL
(+)
(—)
12
3
+12V FROM IGNITION SWITCH
GROUND TO ENGINE BLOCK
RED
GREEN
BROWN
COIL
(+)
(—)
12
3
+12V FROM IGNITION SWITCH
GROUND TO ENGINE BLOCK
LOOM RESISTANCE WIRE
RED
GREEN
BROWN
NOTE—
When using an ACCEL 275+
or 300+ or other aftermarket
ignition control, connect the
MODULE according to the
instructions supplied with the
ignition control.
WITH RESISTANCE WIRE
WITH ACCEL 8140, 8140C, 140108, 140205, 140305 OR 140009 COILS
