About the NTP Swivel Base
Technical Information
Specifications
•
Weight: 44 lb (19.96 kg)
•
Dimensions:
•
Height: 3.30 inches (83.82 mm)(Height can be increased up to 1” using the
adjustable leveling feet)
•
Width: 18.75 inches (476.25 mm) (excluding control knobs)
•
Depth: 23.5 inches (596.9 mm)
•
Retraction Depth: 4.90 inches (124.5 mm)
•
Shipping and Storage Temperature: 0-50°C (32-122°F)
•
Shipping and Storage Relative Humidity: 20% - 80% noncondensing
Swivel Base Label
The NTP Swivel Base displays the following label:
FIGURE 2.
Swivel Base Label
Part Number
Luminex NTP Swivel Base: CN-0251-01
