RT-1000 Remote Trigger Manual
Rev. 12/2012 Page | 23
Daily Start-Up Checklist
ACTIVITIES MUST BE DONE IN THE SEQUENCE SHOWN, AND MUST BE CHECKED
OFF AS COMPLETED. USE THIS CHECKLIST IN CONJUNCTION WITH THE
OPERATING MANUAL FOR THE ULTRAMAX UNIT. THIS SEQUENCE FOLLOWS ON
FROM START- UP CHECKLIST
ACTIVITY NO. CHECK WHEN COMPLETED
Put on Respirator as specified for spray painting, Protective Clothing, Eye Protection, and
PVC Gloves
1 Check all hoses for damage.
2 Check all material supplies and fill or replace as needed.
3 Open main inlet air valve on the manifold.
4 Open recirculation valve on Catalyst Manifold.
5 Close resin dump valve on the bottom of the resin filter.
6 Check pump air regulator and gauge if needed use the regulator on the manifold,
slowly turn up the pump air pressure to the operating pressure, 30 – 50psi. If a
safety over ride valve in installed press and hold the priming button while adjusting
air pressure.
7 Remove the Pivot Pin from the UPS catalyst pump drive.
8 Manually pump the catalyst pump with the UPS drive, observe catalyst returning to
the catalyst jug, pump until the stream is air free.
9 Close recirculation valve on Catalyst Manifold.
10 Manually pump the catalyst pump with the UPS drive, bring catalyst pressure to
operating pressure 100 – 200 psi.
11 Replace the Pivot Pin into the UPS catalyst pump drive.
12 Adjust the catalyst percentage as required.
13 Insert the Distribution Ring into the Mix Chamber locating rim.
14 Place mix housing Seal into the Mix Chamber locating rim.
15 Insert the Catalyst Injector and injector seal into the aperture in the Distribution Ring.
The spring goes into the gun block.
16 Place Mix Chamber and Catalyst Injector onto the front of the Pro Gun, secure it with 2 screws
17 Flush the Assembled mix chamber with solvent.
18 Install mixer and nozzle onto the mix chamber.
THE UNIT IS NOW READY TO BE SET UP FOR SPRAY
ABNORMAL CONDITIONS OBSERVED AND CORRECTED
Abnormal Condition a a a a when corrected
OPERATORS NAME: _____________________________________DATE: ______________
SIGN OFF WHEN START UP CHECKS ARE COMPLETED: ______________________
