Powerslide Powerhead
Powerslide Powerhead
Valve Block Reassembly
NOTE
Removable Lock Tite will be required for reassemble. If ether one of the
two valve rods unscrewed from the valve poppet (MPH-2520) during
disassembly, put one to two drops of removable Lock Tite on threads and
assemble.
1. Set the valve rod assembly into the lower valve block (MPH-2516).
NOTE
The MPH-2500 has a long and short valve rod, insert the short valve rod
(MPH-2519) into the lower valve block. Rotate the valve rod so the hole in
the valve poppet aligns with the pipe plug (PF-AP-04-SS) bore. Insert 7/32”
hex wrench through the pipe plug bore and into the hole in the valve
poppet to hold valve rod assembly in place.
2. Slide the upper valve block (MPH-2515 or VPH-4257) into the lower valve block
(MPH-2516) and align properly. Screw the button head cap screw (F-BHCS-
04C-08-SS) into the lower valve block.
3. Use one to two drops of removable Lock Tite ® in the female threads of the valve
pistons (MPH-2517). (See Figure 3) Shake off any excess Lock Tite ® and
screw onto ether valve rod end. Repeat for process for the second valve piston
and remove hex wrench from valve block. Push in on the valve piston from
ether end to position the valve assembly. Use ether Teflon tape or pipe com-
pound on the pipe plug (PF-AP-04-SS) threads and screw into the lower valve
block.
Chapter
3
