Powerslide Powerhead
Powerslide
Powerhead
Air Cylinder Reassembly
1.
Insert the piston rod (VPH-2502 or MPH-2503) through the piston rod bushing
(MPH-2506). Slide the cylinder (MPH-2502 or VPH-2501) over the piston (MPH-
2501) down onto the lower end cap o-ring (O-B-144).
2.
Set the upper end cap (MPH-2508) onto the cylinder with the valve block flats
facing the same direction. Screw the hex nuts (F-HN-05F) onto the tie rods and
snug the hex nuts.
3.
Install the connectors (APP-9096), sleeve (APP-9109) and e-ring (APP-9102) onto
the piston shaft.
4.
Connect the pilot air hose and regulated air hose to air motor.
Chapter
6
