Powerslide, Powerhead parts drawings – Magnum Venus Plastech Powerhead Powerslide 7000 Series User Manual
Page 22
MAGNUM VENUS PLASTECH Powerslide Dual Rod
22
Powerslide
Powerhead
Parts Drawings
VPH-5000-P
5” Top Slave Arm Powerhead Assembly
VPH-7000-P
7” Top Slave Arm Powerhead Assembly
VPH-7000-P-HD
7” Heavy Duty Top Slave Arm Powerhead
VPH-7000-EPO
7” Powerhead Assembly – EPO Units
VPH-SB-XL
Shift Block for VPH-5000, 7000, 10000
VPH-5000-P-SK
Seal Kit for 5” Top Slave Arm Powerhead
VPH-7000-P-SK
Seal Kit for 7” Top Slave Arm Powerhead
VPH-7000-P-HD-SK
Seal Kit for 7” HD Powerhead Assembly
MPH-SB-XL-SK
Seal Kit for Shift Block
