MAGNUM VENUS PLASTECH Powerslide Dual Rod 13
Powerslide Powerhead
Introduction
This manual covers the Dual Piston Rod
7” diameter by 4” stroke length Powerheads:
VPH-5000-P
5” Top Slave Arm – Powerhead Assembly
VPH-7000-P
7” Top Slave Arm – Powerhead Assembly
VPH-7000-P-HD 7” Heavy Duty Top Slave Arm – Powerhead Assembly
VPH-7000-EPO
7” Powerhead Assembly - EPO
NOTE: It is important to have the correct parts drawing for the Powerhead
you are working on. This will assist in identifying the correct part numbers
for the assembly being rebuilt. The procedures will be the same between
the different configurations but some parts will differ.
The reassembly will require the use of removable Loctite® or equivalent thread
lock compound, Lithium grease (08465) and SUPERLUBE O-ring lubricant.
NOTE: Before starting any service work, release fluid and air pressure from
system. Remove the two air lines from the air motor. In some cases the
Powerhead assembly does not have to be completely removed from the
system for service work.
Please read the manual carefully. Follow the steps in the order given, otherwise
you may damage the equipment or injure yourself.
During Disassembly . . .
As you disassemble the equipment, lay out the components in the correct order
and direction, and have all component drawings available to refer to prior to
disassembly.
This will help you to reassemble them.
CHAPTER
1
