Powerslide Powerhead
Valve Block Reassembly
NOTE: Removable thread lock compound will be required for reassembly. If
either one of the two Valve Rods unscrewed from the Valve Poppet (MPH-
5008) during disassembly, put one to two drops of removable thread lock
compound on threads and assemble.
1. Set the Valve Rod assembly into the Lower Valve Block (MPH-5001).
2. Rotate the Valve Rod so the hole in the Valve Poppet aligns with the Pipe
P lug bore. Insert 7/32” hex wrench through the pipe plug bore and into the
hole in the Valve Poppet to hold Valve Rod assembly in place.
3. Slide the Upper Valve Block (VPH-5001) into the Lower Valve Block (MPH-
5001) and align properly. Screw the Button Head Cap Screw (F-BHCS-04C-
16-SS) into the Lower Valve Block.
4. Use one to two drops of removable thread lock compound in the female
threads of the Valve Pistons (MPH-2517). (See Figure 3) Shake off any
excess thread lock compound and screw onto either Valve Rod end. Repeat
for process for the second Valve Piston and remove hex wrench from Valve
Block.
5. Use either Teflon tape or Pipe compound on the Pipe Plug (PF-AP-04-SS)
threads and screw into the Lower Valve Block.
Figure 3
Use only one to two drops of thread lock
compound in valve piston threads.
