Specifications – Magnum Venus Plastech Flex Molding Process PPVS - VACUUM SENSOR User Manual
Page 24
PPVS (Red) Vacuum Sensor Manual
Rev. 03/2013
Page | 24
Specifications:
Supply pressure:
2 - 6 bar - Use 5 micron filtration.
Operating range:
300 -1000 mb absolute max
Connection port:
Stepped 20 and 25 diameters.
Connection lock:
Proprietary spring clip.
Pipe connections:
Supply - 4mm OD 2.5 ID Recommend flexible polyurethane
Leak Valve – 6mm Poly Tube
Adjustment:
2.5 Allen key.
Contact Materials:
PTFE, cured silicon and Stainless steel.
Weight, dims:
290 grams - 50mm diameter x 86mm H.
