Overview – Magnum Venus Plastech Flex Molding Process PPVS - VACUUM SENSOR User Manual
Page 17
PPVS (Red) Vacuum Sensor Manual
Rev. 03/2013
Page | 17
Overview:
PPVS-INFUSION nose –
(2) 3265 O-rings
Air Supply / Start – Activates the PPVS
Pressure Setting Adjustment –
2.5mm Allen Key
Connection for 6mm Tube to Tee
into MPG leak circuit. Also Time
Delay Setting (Hysteresis)
Adjustment
Leak / Exhaust port
Complete PPVS Kit
