IVx3 Valve Control Box Manual
Rev. 10/2012
Page | 18
PURGER output signal
INJECT output signal
Control Box Connections:
Main Air Inlet – Connect a clean and dry air supply to the control box inlet. This should
be at 6 bar (90 psi) constant air supply. The Control box has an internal regulator set to
6 bar to prevent damage to the PPVS or other valves.
Connecting the Valves – connect the
corresponding IVX3 valve port to the proper port
on the control box using 4 mm tube
Main Air Inlet
IVX3 Valve Control -
Purge / Close / Inject
Modes
6mm Main Air Inlet
