Frp system one gelcoater getting started, Installation – Magnum Venus Plastech System One FRP 1300-1-1 User Manual
Page 6

FRP SystemOne
Gelcoater
Chapter
2
1. Remove unit from crate.
With the crate lying flat, open the top panel and remove the
components:
a. Floor mount assembly
b. Gelcoat pump and pump column
c. Gun and hose set
d. Resin filter and surge chamber assembly
e. Suction wand assembly
f.
Catalyst jug
g. Solvent tank
h. Catalyst pump
i.
Air manifold
2. Assemble pump and column to floor mount assembly.
a. Slide pump column into floor mount and tighten the two hex bolts
in floor mount.
3. Assemble resin filter/surge chamber assembly to pump.
a. Check to make sure all Filter/Surge chamber connections are
tight.
b. Attach the filter/surge chamber assembly to the swivel fitting
located at the outlet of the resin pump.
c. With the filter/surge chamber assembly vertical. Tighten the
fitting with a wrench until it is tight.
FRP SystemOne Gelcoater
Getting Started
Installation
3
