Magnum Venus Plastech PATRIOT HV PAT-LS-49090 User Manual
Page 18
Patriot Fluid Section Manual PAT-LS-49090
Rev. 10/2012
Page | 18
• Piston Valve Disassembly –
12. Unscrew the Piston Valve from the bottom of the Piston Body.
13. Using a pair of Pliers squeeze the Ball Stop and remove it from the Inlet Valve.
14. Remove the Foot Valve Spring and Ball from the Inlet Valve.
NOTE: Use care not to drop the hard chrome balls in the Inlet and Piston
Bodies as they will be damaged. Replace all parts provided in the repair kit.
Use only original MVP parts.
