Patriot Fluid Section Manual PAT-LS-49090
Rev. 10/2012
Page | 16
Fluid Section Removal:
1.
Remove Suction Hose, Resin Hose and Accumulator / Filter assembly from the
Fluid Section. Follow all safety precautions before performing any repairs or
maintenance.
2.
Remove the Sleeve Clip from the shaft, side the Shell Retainer up. Remove the
two Half Shells holding the powerhead and fluid section shafts together.
3.
Use a 3/4” Wrench to unscrew the four Hex Bolts (F-HB-08C-28) holding the
Fluid Section to the Powerhead. Take care to prevent the Fluid Section from
dropping after the bolts are removed.
CAUTION: Remove all fluid pressure and air pressure before beginning
service.
NOTE: Flushing the pumping system with suitable cleaning agent will make
cleaning, repair and maintenance easier.
