Patriot Fluid Section Manual PAT-LS-49090
Rev. 10/2012 Page | 15
Introduction:
This manual covers the repair and rebuilding of the Patriot HV Fluid Section.
• PAT-LS-49090 HV Patriot Fluid Section
Seal Kit:
• PAT-LS-49090-SK
Please read the manual carefully. Follow the steps in the order given, otherwise
you may damage the equipment or injure yourself.
During Disassembly . . .
As you disassemble the equipment, lay out the components in the correct order and
direction. This will help you to reassemble them.
Tools required:
• Red Grease (6706-2-1) (6706-2-16) (6706-2-32)
• Gun Oil (6706-3-1) (6706-3-8) (6706-3-16) (6706-3-32)
• Removable Thread Locking compound
• 3/8-inch Hex Wrench (FR-1026)
• Hex Wrench Set (08469)
• 8-inch Adjustable Wrench (08467)
• 12-inch Adjustable Wrench (08468)
• 1/2-inch Wrench or 1/2" x 9/16” Combination Wrench (08476)
• 9/16-inch Wrench (08476) or 1/2” x 9/16” Combination Wrench (08476)
• 5/8 x 3/4 Combination Box Wrench (08473)
• Repair Kit: PAT-LS-49090-SK
NOTE: Before starting any service work, release fluid and air pressure
from system. Remove the resin hose and suction wand from the fluid
section. The Fluid Section Assembly does not have to be completely
removed from the system for service
work.
