Chapter 3
Removing the Bluetooth board
1. Remove the Upper Cover. See “Removing the Upper Cover” on page 70.
2. Remove the securing screw from the Bluetooth board.
3. Disconnect the mainboard to bluetooth cable as shown.
4. Disconnect the cable from the mainboard.
Step
Size
Quantity
Screw Type
Bluetooth Board
M2*3
1
