Removing the LCD Brackets and FPC Cable
1. Remove the LCD Panel. See “Removing the LCD Panel” on page 94.
2. Turn the LCD panel over to expose the rear. Grip the FPC cable and lift upward to detach the adhesive pads.
3. Remove the eight securing screws (four on each side) from the LCD Panel brackets.
Step
Size
Quantity
Screw Type
LCD Brackets
M2*3
8
