28 Chapter 1
MDC Card
Camera
Finger Print Board
Battery
Item Specification
Chipset Intel® Wireless WiFi Link 5100/5300
Features • The modem supports ITU-T V.92, V.90, V.34 (33600
bits/s), V.32bis and fallbacks.
• It also supports V.42 LAPM, MNP 2-4 error correction.
• V.44, V.42bis and MNP 5 data compression.
• Send and receive rates up to 14400bps, support ITU-T
V.17, V.29, V.27ter, and V.21Ch2 fax.
• TIA/EIA 602 Standard for AT command set, and Fax
TIA/EIA 578 Class 1 command set.
• DTMF and call progress monitor
Item Specification
Vendor and model name Suyin CN0314-SN30-OV03-1
Interface USB 2.0
Optical aperture F2.0
Focusing range 40 cm to infinity
Dimensions (L x W x H mm) 65 x 9.0 x 5.30 (±0.20)
Sensor type OV7725 CMOS Sensor 350K Pixel
Pixel resolution 640 x 480
Pixel size 6.0µm x 6.0µm
Image size (mm) 3.98 (H) x 2.95 (V)
Item Specification
Features TruePrint® and TrueMatch® Technology.
TrueNav® Cursor and Menu Navigation Technology
High Definition 128 x 8 Pixel Array
Multiple battery-friendly operating modes @ 3.3V
Built-in low power Finger Detection w/ remote wakeup
capability
USB 2.0 Full Speed Interface
Item Specification
Vendor & model name Sanyo, Simplo, Sony, Panasonic Sanyo, Simplo, Panasonic
Battery Type Li-ion Li-ion
Pack capacity 4400 mAh 4800 mAh
Number of battery cell 6 8
Package configuration 3S2P 4S2P
