Super-Minature Belt Pack Transmitter

actual roll-off frequency will vary somewhat according

to the low frequency response of the mic capsule being

used.
The low frequency roll-off is used to remove subsonic

(or very low frequency) audio, often produced by air

conditioning systems, automobile traffic and other

sources from the audio signal. Excessive low frequency

content in the audio input can cause a variety of audio

problems including driving the transmitter into limiting.

Input Limiter

A DSP-controlled analog audio limiter is employed

before the analog-to-digital converter. The limiter has a

range of more than 30 dB for excellent overload protec­

tion. A dual release envelope makes the limiter acousti­

cally transparent while maintaining low distortion. It can

be thought of as two limiters in series, connected as a

fast attack and release limiter followed by a slow attack

and release limiter. The limiter recovers quickly from

brief transients, so that its action is hidden from the lis­

tener, but recovers slowly from sustained high levels, to

both keep audio distortion low and preserve short term

dynamic changes.
Two bicolor LEDs indicate limiter activity. (See Operat­

ing Instructions, Adjusting Audio Levels.)

Digital Signal Processor

The DSP encodes the digitized audio from the A-D

Converter and adds an ultrasonic Pilot Tone to control

the receiver’s squelch (only in 400 Series, 200 Series,

IFB Compatibility Mode, and Mode 6 – see Pilot Tone

Squelch). It also controls the input limiter.

Microprocessor, PLL and VCO Circuits

An 8-bit microprocessor monitors user command inputs

from the Control Panel buttons and numerous other

internal signals. It works intimately with the DSP to

ensure the audio is encoded according to the selected

Compatibility Mode and the correct pilot tone is added

to the encoded signal. (See Pilot Tone Squelch.) It

also drives the LCD display and operates the PLL/VCO

circuits.

Compatibility Modes

The SM transmitter was designed to operate with Lec­

trosonics 400 Series receivers and will yield the best

performance when doing so. However, due to the flex­

ibility of digital signal processing, the SM is also able to

operate with Lectrosonics 200 Series, Lectrosonics 100

Series, IFB and certain non-Lectrosonics receivers in

special compatibility modes. (Contact the Lectrosonics

Sales Department for a complete list of non-Lectroson­

ics compatible receivers.)

Pilot Tone Squelch

A fixed frequency pilot tone squelch system (such

as Lectrosonics 200 Series) ensures that a receiver

remains muted until it receives the pilot tone from the

matching transmitter, even if a strong RF signal is pres­

ent on the carrier frequency of the system.

The 400 Series (Digital Hybrid Wireless™) takes this

a step further by using one of 256 different ultrasonic

tones between 25 kHz and 32 kHz to modulate the

carrier and operate the receiver squelch. The pilot

tone frequency is chosen according to which of the 256

channels has been selected. (See SM Screen Selec­

tions.)
This ensures that all transmitters in a system have

different pilot tone frequencies so that even spurious

RF from the wrong transmitters can’t open the receiver

squelch.

Control Panel

A waterproof control panel which includes four mem­

brane switches and an LCD screen is used to set and

adjust the operational settings, and also provide a

visual feedback of overall system operation. (See Con­

trols and Functions.)

Wide-Band Deviation

A ±75 kHz deviation improves the capture ratio, signal

to noise ratio and AM rejection of a wireless system

dramatically, compared to other designs that use 30

kHz to 40 kHz deviation. This combined with a full 100

mW of power output makes a significant improvement in

signal to noise ratio and maximum operating range.

Battery Life

Switching power supplies throughout the design allow

about 4.5 hours of operation using a single AA lithium

battery. If shorter operating times are acceptable, an

alkaline or NiMH battery can be used. AA alkaline bat­

teries provide about 2 hours of operation, and a NiMH

AA battery provides about 3.5 hours of operation.

Note: A NiMH battery will give little or no warning

when it is depleted. If you wish to use NiMH

batteries in the SM, we recommend trying fully

charged batteries in the unit, noting the length of

time that the batteries will run the unit and then

using the battery timer feature available on most

400 Series receivers.

The battery contact is designed to prevent “rattle” as the

unit is handled.

Frequency Agility

The transmitter section uses a synthesized, frequency

selectable main oscillator. The frequency is extremely

stable over a wide temperature range and over time.

256 frequencies in 100 kHz steps over a 25.5 MHz

range are available.

Circulator/Isolator

The RF output circuit includes a one way circulator/

isolator using a magnetically polarized ferrite. This

device greatly reduces RF intermodulation produced

when multiple transmitters are used at separations of

less than five feet. It also provides additional RF output

stage protection but is rarely seen in a wireless micro­

phone transmitter due to its high cost.
