Transmitter front panel, Transmitter rear panel – Lectrosonics Quadra User Manual
Page 18
QUADRA
Transmitter Front Panel
TM
DIGITAL IEM
Headphone
Channel Select Buttons
Power
Monitor
Switch
Transmitter Rear Panel
DIGITAL IEM TRANSMITTER
AES IN
CH1/CH2
1
2
3
4
AES IN
CH3/CH4
USB
ANT
100-240 VAC, 50/60 Hz, 5W
S/N
USB Port for
Antenna Output
Analog Audio Inputs
Power Inlet
Digital Audio
100-240 VAC,
Firmware Updates
Inputs
50/60 Hz, 5 W
LECTROSONICS, INC.
18
