QUADRA
LECTROSONICS, INC. 12
Single Channel Operation
The Single mode allows you to use one M4T transmit­
ter running in the 4 Channel mode to send up to four
mono mixes to up to four different receivers or groups
of receivers using a one radio frequency.
This delivers the selected audio channel to the tall, thin
knob as the master volume. Any one of the four audio
channels sent to the transmitter can be routed to the
master knob. The other three knobs have no function.
NOTE: the transmitter must be in 4 Channel
mode for the receiver to work in this manner.
Press MENU/SEL to select the Knob menu item.
Select desired
audio channel
Use the UP and DOWN arrows to select the desired
channel.
The knob configuration is the same for all four audio
channel selections. The only difference is which audio
channel is delivered to the headphone jack and con­
trolled by the tall, thin knob.
MASTER
VOLUME
AUDIO
CH. 1 NO
FUNCTION
M(1)
NO
FUNCTION
NO
FUNCTION
MASTER
VOLUME
AUDIO
CH. 2 NO
FUNCTION
M(2)
NO
FUNCTION
NO
FUNCTION
MASTER
VOLUME
AUDIO
CH. 3 NO
FUNCTION
M(3)
NO
FUNCTION
NO
FUNCTION
MASTER
VOLUME
AUDIO
CH. 4 NO
FUNCTION
M(4)
NO
FUNCTION
NO
FUNCTION
