Typical Specifications

RF SPECIFICATION
Operating Frequency for the 1900 MHz
Down Link:

1930-1990 MHz

Up Link:

1850-1910 MHz

5MHz, 15MHz, or a combination of a 5 & 15MHz selectable

Operating Frequency for the 850 MHz
Down Link:

869-894 MHz

Up Link:

824-849 MHz

A, A', A" OR B, B' selectable

Output Power:

+13dBm

Gain:

60dB

Flatness:

+0dB, -4dB Full Band

Out of Band Gain:

45dB Offset 1MHz; 35dB Offset 5MHz

NOISE FIGURE
Up Link:

5dB max

VSWR:

1.5 max

Frequency Stability:

±0.05ppM max

ALC:

20dB min

Gain Control Range:

10dB min; 1dB Step

ACPR
CDMA 10FA:

45dBc @ 885KHz

50dBc @ 1.98MHz

Delay:

5usec max

Supply Voltage:

6 V

AC 110~220V to DC 6V SMPS Adaptor

Current Consumption:

4.5A max

DC 6V Current Consumption

ENVIRONMENTAL
Operating Temperature:

-5°C ~ +40°C

Humidity

85%

INDICATORS/CONTROLS
USB Port:

Gain, ALC Level Setting, Alarm

Sleep Mode:

Up Link non signal (below-65dBm): Off

Input over -65dBm: On (in 1 sec)

Oscillation Check:

Observation Down Link

LED:

Shut Down +16dBm

Sleep Mode:

(U/L, D/L)

Shutdown:

(U/L, D/L)

Oscillation:

(D/L)

Power

ALC On/Off:

Setting from GUI

Donor Antenna:

N Type Female

Service Antenna:

Standard SMA Female

PHYSICAL
Dimensions:

8.125" x 8.9375" x 2.9" (W x H x D)

Weight:

7.85 lbs.

AGENCY APPROVAL
FCC Acceptance:

PCS F8I-RPT190AA, Cell F8I-RPT080AA

Industry Canada:

PCS 1208G-RPT190AA, Cell 1208G-RPT080AA
