MP7100 MP7200 MP9200
Model RF Recorder RF Recorder/Player RF Player
TFT Touch Screen Capacity Capacity Resistive
Frequency 48MHz-1GHz
1575.42MHz
25MHz-2.7GHz 25MHz-2.7GHz
Bandwidth 24MHz 20MHz 20MHz
Record ◆ ◆
Play ◆ ◆
Segment Play ◆ ◆
SAI* HDD ◆
SWAP HDD ◆ ◆
Power DC 9V to 36V 120W AC 100-240V AC 100-240V
Size
Weight approx 7Kgw 12Kgw 18Kgw
*Shock Absorber of Independent HDD Mechanism
TX 2.7GHz Up Converter
Block Diagram
MP7200
RX 2.7GHz Down Converter
Block Diagram
PCI - BUS / Interface
A/D Module
20MHz BW
100MS/s
Down Converter
25~2.700MHz
-145~+10dBm
3rd LO
Oscillator
(YIG)
10MHz
Clock
Base
Band
RF
Signal
PCI - BUS / Interface
AWG Module
20MHz BW
200MS/s
Down Converter
25~2.700MHz
-140~-10dBm
3rd LO
Oscillator
(YIG)
10MHz
Clock
Base
Band
RF
Signal
SYSTEM Block Diagram
www.adivic.com
L:27.8xW:24.2xH:23.6 cm L:34.6xW:30.2xH:22.9 cm L:50xW:45xH:20 cm
