MP7200
RF recorder / Player
www.adivic.com
Introduction
ADIVIC RF Recorder,
MP7 SERIES is an
exquisite RF- engineering
tool for both field testing and
performance testing. MP7200 is
engineered for all existing RF
communications and all modulation
schemes, analogue and digital.
MP7200 is capable of RF
signal real-time record
and play.
Idea
All of ADIVIC MP7 Series, with its
small size and light weight design, can
be easily hand-carried to airplane cabin.
All MP7 Series adopt user-friendly TFT-LCD
touch screen. MP7200 RF recorder and player
system covers the frequency spectrum from 25MHz to
2.7GHz.It satisfies various wireless communication
applications. The RF recorder can support a large range of
digital or analog modulation signals in the frequency spectrum.
The RF signal can be stored in a large size HDD. Those all can be
analyzed via MATLAB software or played RF signal by MP7200
or MP9200 RF player.
With the bandwidth of acquisition 24MHz, it allows
the users to record and analyze the wanted
channel signal, adjacent channel signal,
noise/fading signal and any distortion
signals accordingly.
Design
The RF recorder
incorporates a hardware capture
module covering the frequency
spectrum from 25MHz to 2.7GHz.
MP7200 has two RF input interfaces which
can support active and passive antenna types.
The swap HDD and eSATA interface can easily
extend the storage ability.
Each recording can be easily named via the friendly
UI. Remote control function can be operated via
Ethernet RJ45 interface. MP7200 RF player
also supports segment play function.
Users can set any start and stop
points in any RF file to play.
