- 2 -

1. ORDERING GUIDE

Configure a model number in this format: LTE60FR

Transmitter Type

LTE

.

.Pulse input transmitter with 4-20 mA, 0-20

mA or 0-10V isolated analog output, iso-
lated Ethernet serial data output (Modbus
or Custom ASCII protocol), two isolated
solid state relays, and isolated transducer
excitation output. Default jumpered for 10V
excitation.

Main Board

6............................... Standard pulse or AC input
8............................... Extended pulse of AC input

Please see notes for “Extended.”

Power
0
....................................................... 85-264 Vac
1....................................12-32 Vac or 10-48 Vdc
2..........................................Power over Ethernet

Input Type

FR .................. .. Dual Channel Pulse or AC Input

Standard main board

Frequency (2 channels), rate (2 channels), total
(2 channels), period, stopwatch, time interval.

Extended main board

Above plus rate and total simultaneously, linear-
ized inputs using up to 180 points, arithmetic
functions applied to channels A & B (A+B, A-B,
A*B, A/B, A/B-1), phase angle, duty cycle, up/
down counting, batch control.

VF1 ............................. .. 4-20 mA Process Input
VF2 ............................... .. 0-1 mA Process Input
VF3 ................................. .. 0-10V Process Input
VF1 ............................................ .. Custom Input

Standard main board

Rate or total from analog process signals.
Selectable square root extraction for use with
differential pressure flow meters.

Extended main board

Above plus rate and total simultaneously (analog
totalizer), custom curve linearization using up to
180 points, batch control, and time based on
rate.

QD.................................................. .. Quadrature

Standard main board

Position or length from encoders. Accepts diffe-
rential or single-ended inputs: 1x, 2x or 4x, plus
zero index.

Extended main board

Above plus bidirectional rate (rate and position
or length are not simultaneous).
