Technical Description
Sealevel Systems SeaLINK+422
Page 2
Technical Description
The SeaLINK+422: utilizes a USB UART. This chip features programmable baud rate, data format, 128 byte Dual
Port TX Buffer, and 384 byte Dual Port RX Buffer. The RS-422 transceiver supports data rates up to 921.6K baud.
Features
• Hot-Pluggable device
• Does not require opening the case
• No system resources are required (i.e. I/O ports or IRQs)
Connector Pin Assignments (DB-9 Male)
Signal Name
Pin
#
Mode
RX+
Receive Positive
1
Input
RX-
Receive
Negative 2 Input
TX+
Transmit Positive
4
Output
TX-
Transmit Negative
3
Output
GND Ground
5
NC
6,7,8,9
