Technical Specifications
Dimensions
Overall cable length, including connector, is 44”
Length Width Height
2.14” 1.4” 0.63”
5.44 cm
3.55 cm
1.60 cm
Environmental Specifications
Specification Operating Storage
Temperature Range
0º to 70º C
(32º to 158º F)
-50º to 105º C
(-58º to 221º F)
Humidity Range
10 to 90% R.H.
Non-Condensing
10 to 90% R.H.
Non-Condensing
Power Requirements
Supply line
+5 VDC
Rating
100 mA
Manufacturing
All Sealevel Systems Printed Circuit boards are built to UL 94V0 rating and are
100% electrically tested. These printed circuit boards are solder mask over bare
copper or solder mask over tin nickel.
© Sealevel Systems, Inc.
- 17 -
SeaLINK+232-DB9 User Manual
