Specifications
Sealevel Systems ULTRA COMM+422.PCI Page
13
Specifications
Environmental Specifications
Specification Operating Storage
Temperature
Range
0º to 50º C
(32º to 122º F)
-20º to 70º C
(-4º to 158º F)
Humidity Range
10 to 90% R.H.
Non-Condensing
10 to 90% R.H.
Non-Condensing
Manufacturing
• All Sealevel Systems Printed Circuit boards are built to U. L. 94V0 rating
and are 100% electrically tested. These printed circuit boards are solder
mask over bare copper or solder mask over tin nickel.
Power Consumption
Supply line
+5 VDC
Rating
620 mA
Mean Time Between Failures (MTBF)
Greater than 150,000 hours. (Calculated)
Physical Dimensions
Board length
5.0 inches
(12.7 cm)
Board Height including Goldfingers
4.2 inches
(10.66 cm)
Board Height excluding Goldfingers
3.875 inches
(9.841 cm)
