Specifications – Impulse 2101 User Manual
Page 6
Specifications
Sealevel Systems SeaLINK+232 Page
4
Specifications
Specification Operating
Storage
Temperature
Range
0º to 70º C
(32º to 158º F)
-50º to 105º C
(-58º to 221º F)
Humidity Range
10 to 90% R.H.
Non-Condensing
10 to 90% R.H.
Non-Condensing
Manufacturing
All Sealevel Systems Printed Circuit boards are built to UL 94V0 rating and are 100% electrically tested. These
printed circuit boards are solder mask over bare copper or solder mask over tin nickel.
Power Consumption
Supply line
+5 VDC
Rating
50 mA
Physical Dimensions
Package Length
3.8 inches
(9.66 cm)
Package Width
2.3 inches
(5.84 cm)
Package Height
1.0 inches
(2.54 cm)
