Installation – Impulse 3420 User Manual
Page 11
Installation
Sealevel Systems COMM+8 Page
8
Installation
Operating System Installation
For Windows Users
Start by choosing Install Software at the beginning of the CD.
Choose Asynchronous COM: Port Software, SeaCOM.
Other Operating Systems
Refer to the appropriate section of the Serial Utilities Software.
System Installation
The COMM+8 can be installed in any 16-bit PC expansion slot. The
COMM+8 contains several jumper straps for each port that must be set for
proper operation prior to installing the COMM+8 into the computer.
1. Turn off PC power. Disconnect the power cord.
2. Remove the PC case cover.
3. Locate an available slot and remove the blank metal slot cover.
4. Gently insert the COMM+8 into the slot. Make sure that the adapter is
seated properly.
5. Replace the screw.
6. Install the “Octopus” Cable
7. Replace the cover.
8. Connect the power cord.
Installation is complete.
