Installation
Sealevel Systems ULTRA COMM+422 Page
13
Installation
The ULTRA COMM+422 can be installed in any of the PC expansion slots.
The ULTRA COMM+422 contains several jumper straps for each port that
must be set for proper operation.
1. Turn off PC power. Disconnect the power cord.
2. Remove the PC case cover.
3. Locate an available slot and remove the blank metal slot cover.
4. Gently insert the ULTRA COMM+422 into the slot. Make sure that the
adapter is seated properly.
5. Replace the screw.
6. Install the “Spider” Cable
7. Replace the cover.
8. Connect the power cord.
Installation is complete.
Operating System Installation
For Windows Users
Start by choosing Install Software at the beginning of the CD. Choose
Asynchronous COM: Port Software, SeaCOM.
Other Operating Systems
Refer to the appropriate section of the Serial Utilities Software.
