Specifications
Sealevel Systems ACB-MP.PCI Page
4
Specifications
Environmental Specifications
Specification Operating
Storage
Temperature Range
0 to 50 º C
(32 to 122 º F)
-20 to 70 º C
(-4 to 158 ºF)
Humidity Range
10 - 90% R.H. Non Condensing
10 - 90% R.H. Non Condensing
Power Consumption
Supply line
+12VDC -12VDC +5
VDC
Rating
50mA
50mA
350 mA
Mean Time Between Failures (MTBF)
Greater than 150,000 hours. (Calculated)
Physical Dimensions
Board length
4.721 inches
(11.99 cm)
Board Height including Goldfingers
2.536 inches
(6.44 cm)
Board Height excluding Goldfingers
2.211 inches
(5.62 cm)
