© Sealevel Systems, Inc. - 1 - PIO-96.PCI User Manual
Introduction
The PIO-96.PCI part number 8009 digital I/O interface provides 96 channels of
buffered drive digital I/O emulating 8255 mode zero. The PIO-96.PCI can be
utilized for a variety of control and automation applications including control and
monitoring of TTL devices (e.g. LEDs, small solenoids, small relays) and
interfacing to solid-state relay racks (SSRs) for high-power AC or DC loads.
The PIO-96.PCI’s 96 digital I/O channels are accessed via four 50-pin header
connectors with industry-standard pin out. Each header provides 24 bits of digital
I/O divided into three eight-bit groups. Each eight-bit group may be individually
configured via software command as input or output to best match your particular
application requirements.
The PIO-96.PCI is designed to be used with a variety of Operating Systems
including Windows 98/NT/ME/2000/XP, Linux and DOS. The SeaI/O API
(Application Programmer Interface) included on CD with the PIO-96.PCI provides a
variety of useful high-level function calls implemented as a Windows dynamic link
library (DLL) and as a Linux kernel module and library. In addition to the API,
SeaI/O includes sample code and utilities to simplify software development.
Other Sealevel PCI Digital I/O Products
PIO-24.PCI (P/N 8008) - 24 TTL Inputs/Outputs
PIO-32.PCI (P/N 8010) - 32 TTL Inputs/Outputs
PIO-48.PCI (P/N 8005) - 48 TTL Inputs/Outputs
DIO-16.PCI (P/N 8002) - 8 Reed Relay Outputs/8 Opto-isolated Inputs
REL-16.PCI (P/N 8003) - 16 Reed Relay Outputs
DIO-32.PCI (P/N 8004) - 16 Reed Relay Outputs/16 Opto-isolated Inputs
ISO-16.PCI (P/N 8006) - 16 Opto-isolated Inputs
REL-32.PCI (P/N 8007) - 32 Reed Relay Outputs
PLC-16.PCI (P/N 8011) - 8 Form C Relay Outputs/ 8 Opto-isolated
Inputs
