ISO-16 User Manual
IRQ Header E1
Interrupts can be generated by Port A, bit 0 going low if enabled at jumper location
(E1). Interrupt request signals 2/9 through 7 (IRQ 2/9 - 7) can be selected by placing
the jumper in the appropriate position. Other inputs can be ‘wire OR ed.’ to also
generate interrupts if desired. Please consult the factory for more information.
