© Sealevel Systems, Inc. - 11 - DIO-16.LPCI User Manual
Electrical Characteristics
Features
8 SPST relays
1 eight bit optically isolated input port
DB-44 Female connector
Highly reliable 10 VA DIP reed relays
Multiple adapters can reside in same computer
PCI 2.2 Bus compatible
Specifications
Input Ports
Turn On Current: 3 mA
Isolator Diode Drop: 1.1 VDC
Resistor Power Max: .25 W
Output Relays
Contact Max Power Rating: 10 W
Contact Voltage Maximum: 100 VDC/VAC
Contact Current Maximum: .5A AC/DC RMS
Contact Resistance, Initial: .10
Ω
Rated Life:
• Low Load: 200 Million Closures
• Maximum Load: 100 Million Closures
Contact Speed:
• Operate: .5 mS
• Release: .2 mS
• Bounce: .5 mS
Maximum Operating Speed: 600 Hz
Temperature Range
Operating: 0°C – 70°C
Storage: -40°C – 105°C
Power Requirements
+5VDC @ 280 mA
+12VDC (Optional)
Physical Dimensions
PCB Length: 4.721” (11.991 cm)
PCB Height: 2.536” (6.441 cm, including Gold fingers)
