Product Description
The REL-16.PCIe provides16 reed relay outputs. The outputs provide high quality, long life, low current (10
Watt maximum), dry contact switch closures. Reed relays are well suited for low current applications. The
relays are normally open, and close when energized.
The SeaI/O Classic software drivers and utilities are included on the CD and make installation and operation
easy using Windows 7, Vista, and XP operating systems. The SeaI/O API (Application Programmer Interface)
provides a variety of useful high-level function calls implemented as a Windows dynamic link library (DLL)
and as a Linux kernel module and library. SeaI/O also includes sample code and utilities to simplify
software development.
PCI Express X1 compliant
16 Reed relay outputs (SPST)
Highly reliable 10VA Reed relays
Power (+5V and +12V) and ground provided on DB78 board connector
Includes 72” cable with DB78 Male connector to DB37 Maleconnectors (Item# CA490)
SeaI/O Classic software supports Windows 7, Vista, and XP operating systems
Software support for Linux available
