Programming
9 AXB-232++ RS-232/422/485 Interface
Programming
Send_Commands
The AXB-232++ supports the same command set as the AXC-232. The following table lists the
AXB-232++ Send_Commands.
AXB-232++ Send_Commands
B9MOFF
Sets data bit mode to normal
with DIP switch settings
(default).
Syntax:
'B9MOFF'
Example:
SEND_COMMAND AXB232,'B9MOFF'
Sets the data bit mode to normal.
B9MON
Enables a special mode to
override DIP switch settings.
Syntax:
'B9MON'
The mode, nine data bits with one stop bit, overrides the data, stop, and parity
settings. When the AXB-232++ issues this command, it locks in the baud rate
determined by the current DIP switch setting.
Example:
SEND_COMMAND AXB232,'B9MON'
Overrides the DIP switch settings.
BAUDHIGH
Enables 115,200 baud rate
when the DIP switch is set to
300 baud.
Syntax:
'BAUDHIGH'
Example:
SEND_COMMAND AXB232,'BAUDHIGH'
Enables 115,200 baud rate.
BAUDLOW
Enables 300 baud rate when
the DIP switch is set to 300
baud setting (default).
Syntax:
'BAUDLOW'
Example:
SEND_COMMAND AXB232,'BAUDLOW'
Enables 300 baud rate.
BAUDMED
Enables 57,600 baud rate
when the DIP switch is set to
300 baud.
Syntax:
'BAUDMED'
Example:
SEND_COMMAND AXB232,'BAUDMED'
Enables 57,600 baud rate.
CB1ON
Enables placement of charac-
ters in the buffer specified by
CREATE_BUFFER 1
(default).
Syntax:
'CB1ON'
Example:
SEND_COMMAND AXB232,'CB1ON'
Enables placement of characters in the buffer.
CB1OFF
Disables placement of char-
acters in the buffer specified
by CREATE_BUFFER 1.
Syntax:
'CB1OFF'
Example:
SEND_COMMAND AXB232,'CB1OFF'
Disables placement of characters in the buffer.
