MMD-3213M
12
-bit
21.3” grayscale TFT LCD
3MP-2048(H) x 1536(V)
Max. luminace: 800cd/m²
Max. calibrated luminance: 600cd/m²
700:1 exceptional contrast ratio
Out-of-box DICOM compliant
Intelligent display mode auto adjustment with graphic card auto detection
GrayBoost® 12-bit to 12-bit LUT provides simultaneously 4,096 tones of gray
Ready for Deep color and HDMI™ 1.3 with GrayEasy® technology for 12-bit grayscale displaying
54cm(21.3”) Diagnostic Grayscale Monitor
3MP
GeniGUARD® Backlight Stabilizer
Backlight Stabilizer
The GeniGUARD® built-in backlight stabilizer integrated in
PACSmate™ monitors automatically calibrates the shift of LCD brightness
caused by startup drift, ambient temperature and backlight aging.
GrayBoost® 12-bit Simultaneous Grayscale
12-bit (4096 tones) image input can be all retained in 12-bit (4096 tones)
image output via built-in 12-bit LUT. The IEI GrayBoost® technology
successfully produces 12-bit image data flow through commercial dual-
link graphic card, lowering total cost of ownership.
12-bit
8-bit
Original
IEI Factory Calibration
Meets AAPM TG18 & DIN
6868-57 standards
Uniform Luminance
Uniform luminance is especially critical for diagnostic applications and
IEI sets a high standard for the uniformity of every medical monitor.
IEI's special testing equipment ensures every customer gets the medical
monitors with best uniformity for precise diagnostic results.
GrayEasy® HDMI
TM
1.3 Grayscale Support
The GrayEasy® technology successfully produces a HDMI
TM
1.3
compatible, 12-bit grayscale display system without any additional
upgrade cost. The built-in 12-bit to 12-bit Look-Up-Table (LUT) for
DICOM calibration ensures the quality of grayscale images.
Display Mode Auto-Detection
IEI's PACSmate™ medical monitors have built-in auto-detection
technology which identifies different graphic cards automatically and self
adjusts the mode fit with the specific graphic card.
