EMC (MIL-STD 461E/F Compliance)
EMC
Test
Spec
Type of Test
Frequency
Range
Requirement
Default
(√)
Built-in EMI
ITO Glass
or
Mesh Film
Touch
Sensor
CE101
Conducted
Emissions 30Hz ~
10kHz 30Hz ~ 1kHz :110 dB
1k-10k:110-90 dB
√ √
CE102
Conducted
Emissions 30Hz ~
10kHz 10kHz - 500KHz: 100-66dB
,500KHz~10MHz:66dB
√ √
CS101
Conducted
Susceptibility 30Hz -
150kHz
(Above 28 Volts) 30Hz-
5KHz:136dbμV, 5KHz~150k Hz:136-
106.5 dB
√
CS106
Conducted
Susceptibility
transients,
power
leads
(Vpeak = 400 V for 5.0 μsec, ±22%,
Vsag <= 120 V for <=20 μsec)
√
CS109
Conducted
Susceptibility 60Hz -
100kHz
(60-100kHz : 120-60dBμA) √
CS114
Conducted
Susceptibility 10kHz
–200MHz
(10KHz~2MHz:49~89dbμA
, 2MHz~30MHz:97dbμA,
30MHz~200MHz:97~89dbμA)
√
CS115
Conducted
Susceptibility Impulse
Excitation (5A/ 30nS, at a 30 Hz rate for one
minute )
√
CS116
Conducted
Susceptibility 10kHz -
100MHz
(Waveform: e - ( π f t) / Q sin(2πft),
Q = π(N - 1)/ln(IP/IN), Peak current
=10A)
√
RE101
Radiated
Emissions 30Hz -
100kHz
(30-100k :180-110 dBpT) √ √
RE102
Radiated
Emissions 10kHz -
18GHz
(2MHz~18G Hz: 44-89 dB) √ √
RS101
Radiated
Susceptibility 30Hz -
100kHz
(30Hz-100kHz :180-116 dBpt) √
RS103
Radiated
Susceptibility 2MHz -
40GHz (2MHz-30MHz / 30MHz-1GHz /
1GHz-18GHz space :20V/m)
√
» » Mechanical Drawing
9F,No. 111-6, Shing-De Rd., San-Chung City Taipei 241, Taiwan, R.O.C.
Tel: +886-2-8511-0288
Fax: +886-2-8511-0211
Contact Us: [email protected]
Winmate Communication Inc.
www.winmate.com.tw
» » I/O Port Indications
» » Military Grade EMC Compliance
» » Front On-Screen Display Control Functions
AC Power 5xBNCs
(R,G,B,H,V)
VGA DVI Touch/RS232
or remote control
LED
Adjustment
Brightness
Down
Menu Power Auto down
Brightness
Up
UP Light Sensor
Front View Side View Rear View
Bottom View
Environmentals (MIL-STD 810F/G Compliance)
Temperature
Operating
-20°C to 60°C, MIL-STD 810G
Method 501/502, Procedure II
Storage
-40°C to 70°C, MIL-STD 810G
Method 501/502, Procedure I
Temperature
Shock
Operating
-20°C to 60°C, MIL-STD 810G
Method 503.5, Procedure I-B
Humidity
Operating 20°C to 60°C, MIL-STD-810G Method 507.5
Storage 33°C to 63°C, MIL-STD-810G Method 507.5
Altitute Operating
0 to 15,000 ft above sea level
Method 500.5 Procedure II
Shock MIL-STD-810G, Method 516.6
Vibration MIL-STD-810G, Method 514.6 Procedure I
Sand & Dust MIL-STD-810G, Method 510.5 Procedure I
» » Military Grade Environmental Compliance
*
*To have MIL-STD-461E Compliance, it shall have EMI -ITO Glass or
Touch with EMI Mesh Filter
VGA RS232 BNC BNC BNC BNC BNC DVI DC▪IN
GND
205.0
232.5
241.3
205.0
218.7
232.5
241.3
161.9 166.1
199.6
141.9
162.0
199.7
40.0
10.0
85.0
187.5 199.6
187.5
145.4
199.6
320.0
444.0
482.6±1.0
85.0
M6 SCREW D=6mm
218.7
145.4
399.3±1.0
