VMT6008
22
© ads‐tec GmbH • Raiffeisenstr.14 • 70771 Leinfelden‐Echterdingen
6 Interfaces
6.1 Interface Setup
Interface
IRQ
Adress
COM1
4
3F8h
RFID (Touch)
3
2F8h
Pos: 26 /Datentechnik/Schnittstellen/Spannungsversorgung/Spannungsversorgung für VMT60xx-Serie @ 2\mod_1260450284020_6.doc @ 6853 @
6.2 24V DC Power Supply
The supply voltage is provided via a lead‐through terminal including a screw connection (Phoenix Contact
COMBICON MC 1,5/4‐STF3.81). (The figure shows the socket inside the device)
Pin‐Number
Signal‐Name
1
PE
2
0V DC
3
Ignition contact
4
24V DC
Voltage tolerance
•Input voltage: 24 V DC ± 20%.
Current consumption
The current consumption of this device depends on the equipment version
(e.g. if a heater or WLAN, etc. is installed.)
•
Switch‐on current: 7A (1ms)
•
Standby current consumption: 0.25mA
•
Regular operation: 1.3A without heater
(without any additional load on the USB ports and without delivering the +5V supply for the scanner)
Note:
The power supply can be protected with a slow‐blow fuse of up to 4A.
Note:
The typical power consumption of this device is indicated in the "Technical details"
chapter.
