Marine Displays and Computers
© Moxa Inc. All Rights Reserved. Updated Mar. 8, 2013. Specifications subject to change without notice. Please visit our website for the most up-to-date product information.
Specifications
Ordering Information
Available Models
MC-5150-DC-CP: x86-based industrial computer with Intel® Core™ i5 CPU processor, 4 serial
ports, 2 Gigabit Ethernet ports, 6 USB hosts, storage, VGA/DVI, and DC power input
Package Checklist
• MC-5150 computer
• 2 removable storage protection keys
• 4 screws for internal drive tray
• Terminal block for power input
• Hard disk installation kit
• Documentation and driver CD
• Quick installation guide (printed)
• Warranty card
Computer
CPU: Intel® Core™ i5-520E (BGA CPU package), dual core threaded
64 bit 2.4 GHz processor
OS: Windows 7, Windows XP SP3, Windows XP Embedded (must be
installed by the user)
System Chipset: Intel® QM57 Express Chipset
FSB: 1066
System Memory: 2 GB capacity, 2 GB pre-installed: 2 slots of 2 GB
DDR3-1066 204 pin SO-DIMM SDRAM
USB: USB 2.0 hosts x 6, Type A connectors
Storage
Storage Support:
• 1 internal SATA storage tray
• 1 removable SATA storage tray with 64 GB SSD
Other Peripherals
KB/MS: 2 PS/2 interfaces supporting standard PS/2 keyboard and
mouse
Audio: line-in/out interface
Display
Graphics Controller: Onboard Intel® HD graphics
Display Interface:
• VGA Interface: 15-pin D-Sub connector (female), with resolution up
to 1920 x 1080
• DVI-I Interface: 29-pin DVI-I connector (female)
Ethernet Interface
LAN: 2 auto-sensing 10/100/1000 Mbps ports (RJ45)
Magnetic Isolation Protection: 1.5 KV built in
Serial Interface
Serial Standards:
• 2 RS-232/422/485 ports, software-selectable (DB9 male)
• 2 RS-232 ports (DB9)
Serial Communication Parameters
Data Bits: 5, 6, 7, 8
Stop Bits: 1, 1.5, 2
Parity: None, Even, Odd, Space, Mark
Flow Control: RTS/CTS, XON/XOFF, ADDC® (automatic data direction
control) for RS-485
Baudrate: 50 bps to 230.4 Kbps
Serial Signals
RS-232: TxD, RxD, DTR, DSR, RTS, CTS, DCD, GND
RS-422: TxD+, TxD-, RxD+, RxD-, GND
RS-485-4w: TxD+, TxD-, RxD+, RxD-, GND
RS-485-2w: Data+, Data-, GND
LEDs
System: Storage, Power
LAN: 100M/Link x 2, 1000M/Link x 2 (on connector)
Physical Characteristics
Housing: Aluminum, sheet metal
Weight: 3.85 kg
Dimensions: 287 x 250 x 70 mm (11.30 x 9.84 x 2.76 in)
Mounting: Wall
Environmental Limits
Operating Temperature: -15 to 55°C (5 to 131°F)
Storage Temperature: -20 to 60°C (-4 to 131°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Anti-Vibration:
• 0.7 g @ DNV 2.4 (Class A), sine wave, 2-100 Hz, 1 Oct./min., 1.5 hr
per axis
• 1 grms @ DNV 2.4, random wave, 3-100 Hz, 2.5 hr per axis
• 2.1 g @ DNV 2.4 (Class C), sine wave, 2-50 Hz, 1 Oct./min., 1.5 hr
per axis
Power Requirements
Input Voltage: 24 VDC (with tolerance from 18 to 30 VDC, 2-pin
terminal block)
Power Consumption: Less than 100 W, 2.5 A @ 24 VDC
Standards and Certifications
Safety: UL 60950-1, DNV 2.4 (Pending), IEC 60945 (4th) (Pending),
IACS-E10 (Pending), CCC (GB4943, GB9254, GB17625.1)
EMC: EN 55022 Class B, EN 55024-4-2, EN 55024-4-3, EN 55024-4-4,
FCC Part 15 Subpart B Class B
Marine: IEC 60945 4th. (Pending), IACS-E10 (Pending)
Green Product: RoHS, cRoHS, WEEE
Reliability
MTBF (mean time between failures): 220,490 hrs
Warranty
Warranty Period: 3 years
Details: See www.moxa.com/warranty
