Marine Displays and Computers
MC-5150-DC-CP
x86 industrial computer with Intel® Core™ i5 520E, 4 serial ports,
2 Gigabit Ethernet ports, 6 USB hosts, storage, VGA/DVI
The MC-5150-DC-CP computer features the Intel® Core™ i5 520E
processor and come with 4 serial ports, 2 Gigabit Ethernet ports, and
6 USB hosts. The computer offers high performance and versatile
peripherals for marine applications.
Designed with highest quality and durability in mind, the marine-grade
MC-5150-DC-CP computer features a rugged chassis proven against
1G anti-vibration, providing a most reliable platform even in harsh
environments. In addition, the compact size, fanless design, and low
power consumption deliver an optimal thermal solution and make
installation easy for bridge systems in marine applications.
Users can easily install Windows XP Embedded, XP Professional, or
Windows 7, to provide a flexible and friendly environment for system
development and application implementation.
Appearance
Overview
Front View
USB 2.0 x 2
(type A)
Reset Button
System LEDs
(Power, Storage)
Removable Storage Slot
Protection Lock
Power Button
›
High performance Intel® Core™ i5 520E processor, 3 MB L2 cache
›
Built-in 2 GB DDR3 memory, supports up to 4 GB
›
Dual independent displays (DVI-I + VGA)
›
2 Gigabit Ethernet ports for network redundancy
›
2 RS-232/422/485 serial ports
›
2 RS-232 ports
›
6 USB 2.0 hosts
›
1 internal SATA solid state drive storage slot
›
1 removable drive tray with pre-installed 64 GB SSD
›
1G anti-vibration design for system reliability
›
Compact, fanless design
›
Supports Windows XP Embedded, XP Professional, Windows 7
