Specifications
12
Ordering Information
www.lannerinc.com
LVC-5550S Intel® Atom ™ D2550 In-Vehicle Computer, DDR3 SO-
DIMM x1, 2.5” Removable Drive Bay, Mini-PCIe x3 with
one SIM card reader, Intel GbE x2, USB x4, COM x3, DIO,
Audio, DVI-D, VGA, DC Power input +9~30Vdc with Igni-
tion, Suspending Kit included. Dimensions (WxHxD) 268x188.2x56 mm
Processor Intel Atom D2550 Processors
Chipset Intel NM10
System
Memory Technology DDR3 SO-DIMM x1
Max. Capacity Up to 4GB
Storage
IDE CF socket Type I/II x1
SATA Removable 2.5” SSD drive bay x1
Ethernet Controller Intel 82583V x2
Graphic Controller Intel integrated GMA3650 graphic engine
Audio Controller Realtek ALC886 HD codec
IO
LAN GbE RJ45 x2
Display
DB15 x1 for VGA, DVI-D x1, Optional LVDS (integrating USB,
12V and remote power switch)
Audio
1x Mic-in and Line-out (for PC)
1x Mic-in and Line-out (for 3G module)
Serial I/O
DB9 Male x2 supports RS-232/485 with RI/5V/12V
DB9 Male x1 supports RS-232
GPS Ublox NEO-6Q
GPIO
4x DI 12V Level
3x DO 12V Level
2x DI (from MCU) 3.3V Level, 1 x relay (2A, 12V/24V)
USB 2.0 Type A x4,
Power Input 3-pin terminal block (+, -, ignition)
Expansion Mini-PCIex3
Others
External: 3x SMA antenna hole, 1x external SIM-card reader,
1xInternal SIM Card reader, Reset button,Power button, Remote
power switch
Power Input
DC Input: 9~36V for +12V-level and +24V-level car battery
Ignition Control: Support ignition on/off and delay Power-on/off
system, time frame by software setting
Remote power-on: 1. via 3G module. 2. via DI (from MCU)
detection
Power Output 12V, (Max. 1A)
AC Adapter Ordering Option
Hardware Monitor Fintek F81865 integrated watchdog timer 1~255 level
OS Support XPE/WES2009, XP Pro FES, WS7E, WS7P, Win 7 Pro FES
Certifications CE, FCC Class A, E13, RoHS
Compliance
Vibration: MIL-STD-810G, Method 514.6
Shock:MIL-STD-810G, Method 516.6
Operating
Temperature
Range
With Industrial
Components
-30~60°C/-22~140°F
With Commercial
Components
-5~45°C / 23~113°F
