Impulse LVC-5550S - Manual

[email protected] 10 www.lannerinc.com
Diversity of Digital Input/
Output and Relay Support
LVC-5550S supports 2x DI
(Digital Input from MCU) which
can connect sensors to detect
the environment. Once certain
events occur, LVC-5550S can be
turned on automatically. DI/DO
supports 12V level for easy usage
with vehicle parts.1 x relay (2A,
12V/24V) is supported for bigger
driving capability.
Design for MIL-STD-810G with
Extreme Vibration Resistance
LVC-5550S is in compliance with
MIL-STD-810G in vibration and
shock with SSD storage.
Dimensions: 268 x 188.2 x 56 mm
LVC-5550S
Fanless Vehicle PC with Intel
Atom D2550 Processors
Preliminary Specifications
Features
Fanless Design with
Corrugated Aluminum
The corrugated aluminum casing
allow heat to dissipate off the
top of the platform allowing for a
fanless design.
Design for MIL-STD-810G
with Extreme Operating
Temperature
This product is ruggedized to
support a wider than usual range
of temperatures. Outfitted with
industrial components (HDD/SSD,
CF, Memory) this appliance can
thrive in harsh conditions from
-30 to 60°C.
Vehicle Ignition Power
Management
Detects the ignition on/off status
and allow to control delay time by
flexible setting via software utility.
3G Ring/SMS System Power On
LVC-5550S can be turned on
remotely via 3G module by making
ring call or sending SMS.
3G Voice Communication
This vehicle PC supports 3G voice
communication which allows
people can communicate with
operating center through voice
directly.
2x LAN
4x USB
VGA
3x COM
DIO
Remote Power Switch
DC Input
Audio
Removable HDD/SSD
SIM
Card
3G Antenna
DVI-D
Audio
for 3G
12V DC Out
268
302
