PC/104+ SBC - OXY5415A
Block Diagram
Packing List Ordering Information
Intel ® Atom ™
N455
2x8
Pin Header
5V
ICH8-M
VGA
2x10
Pin Header
LVDS 18-bit
LPC
DMI x 4
1 x DDR3 SO-DIMM
up to 2GB
CFAST
SPI BIOS
4 x USB
USB 2.0
HDA
SPI
1 x SATA
SATA
RTL8111DL
PCI Bus
PCIe x1
2x15 Pin Header
RTL8111DL
PCIe x1
PCI-104
PC/104
ITE888G
PCI to ISA
Bridge
ISA Bus
Audio
ALC269
GPIO x 8
1 x RS232
COM1
H/W Monitor
WDT
1 x RS232/422/485
COM2
SMSC
SCH3112
Super I/O
• OXY5415A PC/104+ Module
• CD (Driver + user's manual)
Modules
Model Number Description
OXY5415A-ET PC/104+ Module, Intel® Pineview N455 with DDR3
SO-DIMM, Dual Display by VGA/LVDS PC/104, PCI-
104, Dual GbE LAN, and 5V DC-in
(-20 to 70°C)
Cable Kit
Cable kit for OXY5415A
Thermal Kit
Active heatsink
LAN Kit
LAN card & cable
Stacker Kit
PC/104 stacker (64-pin + 40-pin)
PCI-104 stacker
Optional Accessories
