Page 2
10-56
Dimension
Unit: mm
IMBM-H61B
Ordering Information
Optional Accessories
USB 2.0 Cable
•
LPT Cable
•
CPU Cooler
•
1709070800
•
SATA Cable
1701100302
•
COM Port Cable
Part Number
CPU
RAM
Fan/Fanless
Display
Storage
LVDS
LAN
USB
RS-232 RS-232/422/485
Expansion Slot
Power
Temp.
IMBM-H61B-A10
Socket
DIMM
Fan
VGA x 2
SATA2 x 3
CFast™ x 1
18/24-bit
GbE x 2
USB 2.0 x 8
11
2
PCIe [x16] x 1
PCI x 2
Mini Card x 1
ATX
0°C ~ 60°C
