Specifications
IMBM-H61B
Micro-ATX Industrial Motherboard with Intel® 2nd/3rd Generation Core™ i7/ i5/ i3 Processor
Packing List
Intel® Socket 1155 for 2nd/3rd Generation Core™ Processor
■
■
Intel® H61 Express Chipset
■
■
DDR3 1066/1333 MHz DIMM x 2, Max. 16GB
■
■
VGA x 2, LVDS Dual Independent Displays
■
■
Realtek RTL8111F x 2, Gigabit Ethernet x 2
■
■
COM x 13, USB 2.0 x 8
■
■
PCI-E [x16] x 1, PCI x 2, Mini Card x 1
■
■
System
Form Factor
Micro ATX
Processor
LGA1155 socket for Intel® 2nd/3rd Generation Core™ i7/ i5/ i3/ Pentium® /
Celeron® Processors
System Memory
DIMM x 2, max. 16GB, DDR3 1066/1333 MHz, non-ECC
un-buffered memory, Dual channel memory architecture
Chipset
Intel® H61 Express Chipset
I/O Chipset
Fintek 81866D (5 COM) + Fintech 81216HD (8 COM) x 2
Ethernet
Realtek RTL8111F x 2, Gigabit Ethernet, RJ-45 x 2
BIOS
64Mbit Flash ROM, AMI BIOS
Wake On LAN
Yes (WOL / PXE)
Watchdog Timer
1~255 steps by software program
H/W Status Monitoring
Temperature Monitor on CPU/System Voltage Monitor on Vcore/5V/VBAT/12V
Fan Monitor on CPU/ Chassis
Expansion Interface
PCIe 2.0 [x16] x 1, PCI x 2, Mini Card x 1
Battery
Lithium battery
Power Requirement
24-pin ATX connector x 1, 4-pin ATX 12V Power connector x 1
Power Consumption
(Typical)
Intel® Core™ i5-2390T, DDR3 1333 8GB
3.9A@12V
Board Size
9.6" x 9.6" (244 mm x 244 mm)
Gross Weight
1.55 lb (0.7 Kg)
Operation Temperature
32°F ~ 140°F (0°C ~ 60°C)
Storage Temperature
-40°F ~ 185°F (-40 °C ~ 85°C)
Operation Humidity
0% ~ 90% RH, non-condensing
MTBF (Hours)
87,000
Display
Chipset
Intel® Graphics Media Accelerator
Graphic Engine
Intel® HD Graphic Support, Dual independent Display
Resolution
Up to 1920 x 1200 @75 Hz for VGA
Up to 1920 x 1200 @60 Hz for LVDS
Output Interface
VGA x 2 , LVDS
I/O
Storage
SATA 3.0Gb/s x 3, CFast™ socket x 1
Serial Port
RS-232 on back panel (COM1&COM2) x 2,
RS-232/422/485 with onboard box header x 2
RS-232 with onboard box header x 9
Digital I/O
8-bit Digital I/O interface (4-in /4-out)
Universal Serial Bus
USB 2.0 x 8, 4 ports on mid-board, 4 ports on back panel)
PS/2 Port
PS/2 Port (Keyboard & Mouse) x 2
Audio
Line-in, Mic-in, Line-out
COM Port Cable
•
SATA Cable x 2
•
I/O Shield
•
Product CD
•
IMBM-H61B
•
Launching in Q1
