34
R E P A I R P A R T S
SERVICE KITS
ITEM PART # DESCRIPTION
K1 71-B120 Brake kit - 115 Volt models
71-B240 Brake kit - 230-460 Volt models
71-B575 Brake kit - 575 Volt models
Complete with: Brake hub kit, brake
release lever, brake disk, spring cup,
studs, compression springs, brake
solenoid, solenoid cover, spacers,
mounting plate, pressure plate, feather
key and conduit.
K2 K75-34824 Chain guard kit
Complete with: Chain guard, chain
guides and retainers.
K3 K75-34828 Idler shaft kit
Complete with: Bearings, sprocket
50B12x1" and idler shaft
K4 K75-34842 Cover kit
Complete with: Cover and lock bar
K5 K29-32410 Alarm kit
Complete with: Alarm and cable
K6 K75-19977 Disconnect kit
K7 K72-34844 Output shaft kit
Complete with: Output shaft,
sprockets, e-ring, washer, key, set
screw, roll pin and spacer.
K8 K72-34845 Clutch shaft kit
Complete with: Clutch shaft,
sprockets, e-ring, compression spring,
pulley, washer, bearings, retaining
ring, disconnect splined hub and roll
pin.
NOT SHOWN
19-48047M Roller Chain (Sprocket Reduction)
K1C3196-3 Antenna
INDIVIDUAL PARTS
ITEM PART # DESCRIPTION
1 22-120 Brake solenoid, 115V
22-240 Brake solenoid, 230-460V
22-575-1 Brake solenoid, 575V
2 80-9001 Feather key
3 12-4164 Flange bearing mount
4 15-50B24LGH Drive sprocket, 50B24 x 1"
5 10-30678 Lock bar
6 23-34815 Stop/Reset button
7 16-5L304 V belt cogged
8 17-6014 Motor pulley
9 K20-1050B-2P Motor - models SL575-50-11,
SL575-50-21, SL575-50-81
K20-1100B-2P Motor - models SL575-100-11,
SL575-100-21, SL575-100-81
K20-3050B-4P Motor - model SL575-50-23,
SL575-50-43, SL575-50-83
K20-3100B-4P Motor - models SL575-100-23,
SL575-100-43, SL575-100-83
K20-3100M-5 Motor - model SL575-100-53
VARIABLE PARTS
10 23-20088 On/off switch - 1 phase 115V
23-3001 On/off switch - 1 phase 208/230V
23-3005 On/off switch - 3 phase
NOT SHOWN
01-34851 Owner’s manual - English
01-34851SP Owner’s manual - Spanish
01-34851FR Owner’s manual - French
