RAM 302
RAMSET
www.ramsetinc.com
7
STANdArd iNSTALLATiON FOr gATES FrOm 8’ TO 14’ iN LENgTh
Note:
15 amp wires connected to independent
breaker.
Gate travel is adjusted by loosening the limit Cams
and adjusting them until proper gate travel has been
achieved.
hOOkup ELECTriCAL pOwEr
gATE TrAvEL AdJuSTmENT
Figure 3
Figure 5
Figure 4
Outlet
Leads
